Network technology
GSM / CDMA / HSPA / EVDO / LTE
Network 2g bands
GSM 850 / 900 / 1800 / 1900- SIM 1 & SIM 2 (dual-SIM model only)CDMA 800 / 1900- USA
Network 3g bands
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100- Global, USACDMA2000 1xEV-DO- USA
Network 4g bands
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 38, 39, 40, 41, 66- Global1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 46, 66, 71- USA
Network speed
HSPA 42.2/5.76 Mbps, LTE-A (7CA) Cat20 2000/150 Mbps
Launch announced
2019, February 20
Launch status
Available. Released 2019, March 08
Body dimensions
142.2 x 69.9 x 7.9 mm (5.60 x 2.75 x 0.31 in)
Body weight
150 g (5.29 oz)
Body build
Glass front (Gorilla Glass 5), glass back (Gorilla Glass 5), aluminum frame
Body sim
Single SIM (Nano-SIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by)IP68 dust/water resistant (up to 1.5m for 30 mins)
Display type
Dynamic AMOLED, HDR10+
Display size
5.8 inches, 82.8 cm2 (~83.3% screen-to-body ratio)
Display resolution
1080 x 2280 pixels, 19:9 ratio (~438 ppi density)
Display protection
Corning Gorilla Glass 5Always-on display
Platform os
Android 9.0 (Pie), upgradable to Android 12, One UI 4
Platform chipset
Exynos 9820 (8 nm)- EMEA/LATAMQualcomm SM8150 Snapdragon 855 (7 nm)- USA/China
Platform cpu
Octa-core (2x2.73 GHz Mongoose M4 & 2x2.31 GHz Cortex-A75 & 4x1.95 GHz Cortex-A55)- EMEA/LATAMOcta-core (1x2.84 GHz Kryo 485 & 3x2.42 GHz Kryo 485 & 4x1.78 GHz Kryo 485)- USA/China
Platform gpu
Mali-G76 MP12- EMEA/LATAM Adreno 640- USA/China
Memory card slot
microSDXC (uses shared SIM slot)- dual SIM model only
Memory internal
128GB 6GB RAM, 128GB 8GB RAM, 256GB 8GB RAMUFS 2.1
Main camera features
LED flash, auto-HDR, panorama
Main camera video
4K@60fps (no EIS), 4K@30fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, stereo sound rec., gyro-EIS & OIS
Selfie camera single
10 MP, f/1.9, 26mm (wide), 1/3", 1.22m, Dual Pixel PDAF
Selfie camera features
Dual video call, Auto-HDR
Selfie camera video
4K@30/60fps, 1080p@30fps
Sound loudspeaker
Yes, with stereo speakers
Sound 35mm jack
Yes32-bit/384kHz audio Tuned by AKG
Comms wlan
Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct, hotspot
Comms bluetooth
5.0, A2DP, LE, aptX
Comms gps
Yes, with A-GPS, GLONASS, BDS, GALILEO
Comms nfc
Yes
Comms radio
FM radio (USA & Canada only)
Comms usb
USB Type-C 3.1
Features sensors
Fingerprint (side-mounted), accelerometer, gyro, proximity, compass, barometerANT+ Bixby natural language commands and dictation Samsung Pay (Visa, MasterCard certified)
Battery charging
Fast charging 15W USB Power Delivery 2.0 Fast Qi/PMA wireless charging 15W Reverse wireless charging 4.5W
Misc colors
Prism White, Prism Black, Prism Green, Prism Blue, Canary Yellow, Flamingo Pink
Misc models
SM-G970F, SM-G970U, SM-G970W, SM-G9700, SM-G970U1, SM-G970N
Misc sar
0.56 W/kg (head) & & 0.70 W/kg (body) & &
Misc sar eu
0.58 W/kg (head) & & 1.57 W/kg (body) & &
Misc price
$251.16 / 465.00 / 437.00 / C$508.32 / Rp2,659,300
Tests performance
AnTuTu: 325192 (v7), 389694 (v8) GeekBench: 10081 (v4.4), 2141 (v5.1) GFXBench: 40fps (ES 3.1 onscreen)
Tests display
Contrast ratio: infinite
Tests camera
Photo / Video
Tests loudspeaker
Voice 71dB / Noise 76dB / Ring 80dB
Tests battery life
Endurance rating 83h
