Network technology
GSM / CDMA / HSPA / EVDO / LTE
Network 2g bands
GSM 850 / 900 / 1800 / 1900 CDMA 800 / 1700 / 1900 / 2100
Network 3g bands
HSDPA 850 / 900 / 1700 / 1900 / 2100 CDMA2000 1xEV-DO
Network 4g bands
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 29- A16881, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41- A1687
Network speed
HSPA 42.2/5.76 Mbps, LTE-A (2CA) Cat6 300/50 Mbps, EV-DO Rev.A 3.1 Mbps
Launch announced
2015, September 09
Launch status
Available. Released 2015, September 25
Body dimensions
138.3 x 67.1 x 7.1 mm (5.44 x 2.64 x 0.28 in)
Body weight
143 g (5.04 oz)
Body build
Glass front (Gorilla Glass), aluminum back, aluminum frame
Body sim
Nano-SIMApple Pay (Visa, MasterCard, AMEX certified)
Display type
IPS LCD capacitive touchscreen, 16M colors
Display size
4.7 inches, 60.9 cm2 (~65.6% screen-to-body ratio)
Display resolution
750 x 1334 pixels, 16:9 ratio (~326 ppi density)
Display protection
Ion-strengthened glass, oleophobic coating3D Touch
Platform os
iOS 9, upgradable to iOS 13.5
Platform chipset
Apple A9 (14 nm)
Platform cpu
Dual-core 1.84 GHz Twister
Platform gpu
PowerVR GT7600 (six-core graphics)
Memory card slot
No
Memory internal
16GB 2GB RAM, 32GB 2GB RAM, 64GB 2GB RAM, 128GB 2GB RAM
Main camera single
12 MP, f/2.2, 29mm (standard), 1/3", 1.22m, PDAF
Main camera features
Dual-LED dual-tone flash, HDR
Main camera video
4K@30fps, 1080p@60fps,1080p@120fps, 720p@240fps
Selfie camera single
5 MP, f/2.2, 31mm (standard)
Selfie camera features
Face detection, HDR, panorama
Selfie camera video
1080p@30fps
Sound loudspeaker
Yes
Sound 35mm jack
Yes16-bit/44.1kHz audio
Comms wlan
Wi-Fi 802.11 a/b/g/n/ac, dual-band, hotspot
Comms bluetooth
4.2, A2DP, LE
Comms gps
Yes, with A-GPS, GLONASS, GALILEO, QZSS
Comms nfc
Yes (Apple Pay only)
Comms radio
No
Comms usb
2.0, proprietary reversible connector
Features sensors
Fingerprint (front-mounted), accelerometer, gyro, proximity, compass, barometerSiri natural language commands and dictation
Battery
Non-removable Li-Ion 1715 mAh battery (6.91 Wh)
Misc colors
Space Gray, Silver, Gold, Rose Gold
Misc models
A1633, A1688, A1691, A1700
Misc sar
1.14 W/kg (head) & & 1.14 W/kg (body) & &
Misc sar eu
0.87 W/kg (head) & & 0.98 W/kg (body) & &
Misc price
$119.99 / 165.69 / 175.00 / 28,999
Tests performance
Basemark OS II 2.0: 2195
Tests display
Contrast ratio: 1481 (nominal), 3.783 (sunlight)
Tests camera
Photo / Video
Tests loudspeaker
Voice 66dB / Noise 64dB / Ring 65dB
Tests battery life
Endurance rating 62h
